Engine Oil Level Check

NOTE: Always check the oil level with the watercraft level and the engine COLD.
1. Start engine and run for no more than 30 -- 45
seconds.
2. Remove the oil dipstick from the top of the oil storage
tank. Wipe clean with shop towel.
3. Re--insert the dip stick into the oil storage tank, but do
not thread into tank. Remove the dipstick, and check
oil level.
The oil level should be between the MIN and MAX marks.
The volume between the MIN and MAX marks is .5 Us
Quarts (.5L).
The oil level will rise as the engine warms up to operating
temperature, but SHOULD NEVER RISE PAST THE
OVERFILLED MARK. Remove oil from tank if level is
above MAX mark after warming engine to operating tem-
perature.
Warming the engine up can be accomplished by installing
a flush kit. Never exceed 2000 RPM when connected to
a flush kit.
CAUTION:
Never allow the oil level to exceed the OVERFILLED OIL LEVEL mark on the top of the dipstick. Severe engine
damage may occur.
ENGINE OIL SPECIFICATION
POLARIS MARINE PS--4 SYNTHETIC 15W--50
PN: SEE PAGE 2.4
ROUTINE OIL CHANGE: 3.4 -- 3.7 US QUARTS
NEW ENGINE: 3.9 -- 4.2 US QUARTS
3.7 -- 4.0 LITERS
BREAK IN: 12 HOURS
EVERY 25 HOURS AFTER BREAK IN PERIOD

Oil Change Procedure

1. Remove the oil fill cap located on the top of the oil
storage tank.
2. Using a oil extraction / storage tool, insert the hose into
the oil storage tank.
NOTE: To prevent oil foaming, a baffle is located
inside the tank. Verify the hose passes through one
of the baffle holes and reaches the bottom of the
tank.
3. Extract ALL of the oil out of the storage tank into the
storage container. Remove the hose, and replace the
cap when all of the oil is removed.
2.10
MAINTENANCE
3.3 -- 3.5 LITERS
OVERFILLED OIL LEVEL
MAXIMUM OIL LEVEL (HOT)
.5 US Qt. (.5 L)
MINIMUM OIL LEVEL
