FUEL INJECTION / IGNITION / EXHAUST SYSTEMS
Manifold Pressure Circuit
ECU 300 (Black)
A B C D E F G H
4
3
2
1
A B C D E F G H J K
3
1
A B C D E F G
3
1
ECU 100 (Grey)
Circuit Trouble Codes
P - - Code
P0105 Intake Manifold Pressure: Plausibility Error
P0106 Intake Manifold Pressure: Signal Error
P0107 Intake Manifold Pressure: Short to Ground
P0108 Intake Manifold Pressure: Short to Battery
2004 Four Stroke PWC Service Manual
L M
4
2
H
Reference
C3
5- -Volt
4
2
C2
Ground Reference
Manifold Pressure Sensor
C1
Description
Manifold Pressure
Sensor
Splice 5
Splice 4
Summary
The measured intake manifold pressure is outside an acceptable
range.
the intake manifold pressure is outside an acceptable range, but
not shorted to ground or battery voltage.
The intake manifold pressure signal is shorted to ground.
The intake manifold pressure signal is shorted to battery voltage.
1
2
3
4
5.21
