System Interface Box (SIFB)
ECU
ECU 200
GRY
J2
BLU/WHT
B4
GRN/YEL
E2
SYSTEM INTERFACE BOX (SIFB) -- LEGEND
RED/PUR 12V BATTERY VOLTAGE
BLACK GROUND
GRN/YEL REVERSE SWITCH SIGNAL (FROM IFB)
BLU/WHT IGNITION SWITCHED VOLTAGE (FROM IFB)
GRY TACHOMETER SIGNAL
RED/YEL IGNITION SWITCHED VOLTAGE (FROM START BUTTON)
YEL/GRN REVERSE SWITCH SIGNAL (FROM REVERSE SWITCH)
PURPLE IGNITION SWITCHED VOLTAGE (FROM TETHER SWITCH)
Rev. A 11/05/2003
8.12
ELECTRICAL SYSTEMS
SYSTEM INTERFACE BOX
A B C D E F G H
YEL/GRN
RED/PUR
BLACK
ENGINE/CHASSIS HARNESS CONNECTOR
PURPLE
YEL/GRN
E D
F G
GRY
RED/YEL
11 3
MAIN RELAY
R2
2 10 13
2004 Four Stroke PWC Service Manual
B A
H J K
15 8
R1
6 5 4 7
