Polaris msx 110 Service Manual page 234

RED
SPLICE 3
- -
+
BATTERY
STARTER RELAY
RED/PUR
H G F E
A
B C D
SYSTEM IFB CONNECTOR
ECU
ECU 100
BLK/GRN
F3
ECU 200
GRN/RED
C4
PUR/WHT
E3
GRN/YEL
K3
GREY
J2
ECU 300
F2
RED/PUR
G2
ENGINE HARNESS
FUSE SPLICE BLOCK
RED RED/PUR
C D
15A
RED
E F
15A
RED
A B
15A
RED/PUR
11 3
R2
2 10
LAMBDA SENSOR
BLK/GRN
GRN/YEL
RED/PUR
15 8
MAIN RELAY
R1
13 6 5 4 7
BLK/GRN
RED/PUR
RED/PUR
RED/PUR
PUR/WHT
GRN/RED
GREY
MAIN RELAY CIRCUITS -- LEGEND
RED 12V BATTERY VOLTAGE
BLACK GROUND
RED/PUR FUSE PROTECTED / RELAY SWITCHED BATTERY VOLTAGE
PURPLE SWITCHED ECU VOLTAGE FROM TETHER SWITCH
BLK/GRN SWITCHED ECU RELAY CONTROL
LT.BLUE OIL PRESSURE SWITCH SIGNAL
GRN/RED CHECK ENGINE MIL SIGNAL
PUR/WHT ESP SIGNAL
GRN/YEL ENGINE TEMP . MIL SIGNAL / EXHAUST PIPE WATER TEMP . MIL SIGNAL
GREY TACHOMETER SIGNAL
Rev. B 1/12/2004
MAG FUEL INJECTOR
RED/PUR
WASTEGATE SOLENOID
SPLICE 1
RED/PUR
RED/PUR
PTO FUEL INJECTOR
MAG IGNITION COIL
RED/PUR
SPLICE 2
RED/PUR
RED/PUR
E D B A
F G H J K
LT.BLUE
ENGINE/CHASSIS HARNESS CONNECTOR
PTO IGNITION COIL
OIL PRESSURE SWITCH
