FUEL INJECTION / IGNITION / EXHAUST SYSTEMS
Engine Crankshaft Position (Engine Speed) Sensor Circuit
ECU 300 (Black)
A B C D E F G H
4
3
2
1
A B C D E F G H J K L
3
1
1
A B C D E F G H
2
3
3
1
ECU 100 (Grey)
Circuit Trouble Codes
P - - Code
P0335 Loss of Synchronization
P0336 Engine Speed Sensor: Signal Error
P0337 Engine Speed Sensor: Low Limit
P0338 Engine Speed Sensor: High Limit
2004 Four Stroke PWC Service Manual
M
4
2
4
2
Description
B1 Crank Signal A
B2 Crank Signal B
A3 Ground Reference
The number of pulses, or teeth on the timing rotor are not cor-
rect.
The engine speed sensor signal is not valid.
The engine speed signal voltage is outside the acceptable range.
The engine speed signal voltage is outside the acceptable range.
1
Crankshaft
2
Sensor
3
Summary
5.23
