Polaris msx 110 Service Manual page 233

TETHER SWITCH
START SWITCH
RED/PUR
CLOSED WHEN TETHER INSTALLED
YEL/RED
PURPLE
PUR/WHT
E D B A
YEL/RED
F G H J K
ENGINE - - CHASSIS
CONNECTOR
LT.BLUE
GRN/YEL
RED
YEL/RED
A B
BLACK
- -
+
BATTERY
STARTER RELAY
RVS SWITCH
Y/GRN
A B
RED/PUR
RED/PUR
GRAY
RED
GRN/RED
RED/PUR
RED
RED
B A C D E
2A 10A 15A
CHASSIS WIRING HARNESS -- LEGEND
RED
BLACK
RED/PUR
YEL/RED
PUR/WHT
PURPLE
OR/BLK
MODE SWITCH
Y/GRN
PUR/YEL
GRAY
LT.BLUE
PINK
A B
GRN/YEL
GRN/RED
Rev. A 11/05/2003
PUR/WHT
RED/PUR
RED/PUR
FUEL PUMP
F
1 2 3 4
BLACK
PINK
12V BATTERY VOLTAGE
CHASSIS GROUND
FUSE PROTECTED / SWITCHED BATTERY VOLTAGE
STARTER RELAY SIGNAL
ESP SIGNAL
SWITCHED ECU VOLTAGE
NGI MODE SWITCH SIGNAL
REVERSE SWITCH SIGNAL
PADDLEWHEEL SIGNAL
TACHOMETER SIGNAL (2 PULSE)
OIL PRESSURE SWITCH SIGNAL
FUEL LEVEL SIGNAL
ENGINE TEMPERATURE SWITCH
CHECK ENGINE MIL LAMP SIGNAL
OR/BLK
GRAY
ESP SWITCH
A B
PUR/WHT
GRN/RED
BLUE
GRN/YEL
PINK
PUR/YEL
BLACK
NGI GAUGE
E F
C B A
C B A
D E
BLACK
PADDLE WHEEL
