Engine Removal and Installation - - Continued
UPPER- -TO- -LOWER
BRACKET FASTENERS x3
UPPER BRACKET
WATER- -TO- -WATER
HEAT EXCHANGER
19. With the fasteners removed, carefully slide the intake
manifold towards the rear of the engine compartment
and out of the watercraft.
20. Slide the heat exchanger towards the rear, then
remove from engine compartment. (Photo H)
21. Remove the two fasteners that secure the lower
bracket to the engine. Remove the lower bracket.
2004 Four Stroke PWC Service Manual
ENGINE REMOVAL / INSTALLATION
MANIFOLD FASTENERS x4
INTAKE MANIFOLD
LOWER BRACKET
LOWER BRACKET FASTENERS x2
PHOTO H
3.5
