ENGINE DISASSEMBLY / ASSEMBLY
Internal Engine Coolant Hose Routing - - Right View
ENGINE COOLANT HOSE
(FROM WATER OUTLET RAIL TO
OIL TANK - - THERMOSTAT
CLOSED)
ENGINE COOLANT HOSE
(FROM EXPANSION TANK
TO WATER PUMP)
ENGINE COOLANT HOSE
(FROM THERMOSTAT HOUSING
TO HEAT EXCHANGER - - THER-
MOSTAT OPEN)
ENGINE COOLANT HOSE
(FROM HEAT EXCHANGER TO OIL
COOLER - - THERMOSTAT OPEN)
4.64
2004 Four Stroke PWC Service Manual
