Standard Torque Specifications

The following torque specifications are to be used as a general guideline. Use standard torque values for the
appropriate size fastener when torque values are not specified. Always consult the specific manual section
for torque values of fasteners and use of locking agent. When fastener replacement is required, use only
genuine Polaris fasteners.
Bolt Size
8
10
1/4
5/16
3/8
3/8
7/16
1/2
1/2
Bolt Size
1.10
GENERAL INFORMATION
RECOMMENDED TORQUE SPECIFICATION
STAINLESS STEEL FASTENERS (SAE)
Threads/Inch
18 & 32
24 & 32
20 & 28
18 & 24
RECOMMENDED TORQUE SPECIFICATION
STAINLESS STEEL FASTENERS (METRIC)
5mm
6mm
8mm
10mm
12mm
16
24
14
13
20
2004 Four Stroke PWC Service Manual
Torque
28 in. lbs.
40 in. lbs.
8 ft. lbs.
14 ft. lbs.
25 ft. lbs.
28 ft. lbs.
40 ft. lbs.
58 ft. lbs.
70 ft. lbs.
Torque
45-52 in. lbs.
66-78 in. lbs.
13-16 ft. lbs.
26-30 ft. lbs.
40-44 ft. lbs.
