Start / Stop Electrical System
RED
- -
+
STARTER RELAY
YEL/RED
A
BLK
B
RED
RED
START / STOP CIRCUITS -- LEGEND
RED 12V BATTERY VOLTAGE
BLACK GROUND
RED/PUR FUSE PROTECTED / SWITCHED BATTERY VOLTAGE
YEL/RED STARTER RELAY SIGNAL
RED/YEL STARTER RELAY SIGNAL
PURPLE SWITCHED ECU VOLTAGE
BLU/WHT SWITCHED ECU VOLTAGE
Rev. B 1/19/2004
8.10
ELECTRICAL SYSTEMS
B
2A
C
10A
F
15A
PURPLE
D
D
PURPLE
H
SYSTEM INTERFACE BOX
RED/PUR
A
TETHER SWITCH
D
E
A
PURPLE
C
YEL/RED
B
START SWITCH / STOP - - TETHER
YEL/RED
ENGINE HARNESS- - TO- - CHASSIS
F
HARNESS CONNECTOR
F
RED/YEL
C A
ECU 200
BLU/WHT
BLK
2004 Four Stroke PWC Service Manual
START SWITCH
ECU
ECU 100
B4
L4
ECU 300
