Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
2
Select frequency area in the Frequency drop-down list.
3
Click "OK".
4
Reset in order to make the changes take effect, see
8.5.7
Enable Carriers
The IPBS/IPBL has 5 carriers for the North American frequency band and 10 carriers for the
other frequency bands. Under all normal circumstances all carriers should be enabled.
To enable or disable carriers:
1
Select DECT > System.
NOTE: To access the System tab, the Master mode has to be activated, see
Select Mode
2
Select/clear the Enabled Carriers check boxes.
3
Click "OK".
8.5.8
Local R-Key Handling
With this option enabled keypad information is handled locally. If this option is disabled
keypad information is sent transparently to the IP-PBX. Local R-key handling is further
described in
1
Select DECT > System.
NOTE: To access the System tab, the Master mode has to be activated, see
Select Mode
2
To enable, select the Local R-Key Handling check box.
NOTE: To access the Local R-Key Handling check box, the SIP protocol has to be
selected on the Master, see
3
Click "OK".
8.5.9
No Transfer on Hangup
If enabled it will not be possible to do a transfer by hanging up the handset. R4 must be
pressed (see
1
Select DECT > System.
NOTE: To access the System tab, the Master mode has to be activated, see
Select Mode
2
To enable, select the No Transfer on Hangup check box.
3
Click "OK".
8.5.10 Configure Coder
Select the preferred coder, and enter the desired frame length. If exclusive is selected for
the coder the IPBS/IPBL is forced to use that coder. With Silence Compression enabled no
information is sent during pauses in the conversation, this is used to save bandwidth.
Note: When exclusive is enabled for a coder it might be impossible to make calls outside
the IP-DECT system.
15 February 2012 / Ver. H
on page 94.
Appendix
C.
on page 94.
8.5.16 Configure Gatekeeper
Appendix
C).
on page 94.
TD 92579EN
8.22 Reset
on page 138.
8.5.13
8.5.13
on page 95.
8.5.13
91
