Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
Tip: To assign a PARI Master, see
Standby PARI Master
1 Select DECT > Radio.
2 Clear the Disable check box.

8.5.23 Enter IP Address to the PARI Master and the Standby PARI Master

All IPBS/IPBL need to know the IP address of the PARI Master and the Standby PARI Master.
1 Select DECT > Radio.
2 Enter the name for the PARI Master in the Name text field.
3 Enter the password for the PARI Master in the Password text field.
4 Enter the address to the PARI Master in the PARI Master IP Address text field. If this
is the PARI Master, enter 127.0.0.1.
5 Enter the address to the Standby PARI Master in the Standby PARI Master IP Address
text field. If this is the Standby PARI Master, enter 127.0.0.1.
6 Click "OK".
7 Reset in order to make the changes take effect, see

8.5.24 Multiple Radio Configuration

The PARI Master can configure the same Radio settings for all Radios in the system. All
settings configured in the Radio Config page replace the local Radio settings. This means
that all settings in the Radio Config menu will have precedence over values configured
locally or received via DHCP options.
1 Select DECT > Radio Config.
NOTE: To access the Radio Config. tab, the PARI function has to be enabled, see
8.5.15 Enable PARI Function
2 Configure alarm and event forwarding, see
3 Configure automatic firmware update, see
Update
4 Configure NTP settings, see
5 Configure IP settings, see
6 Click "OK".

8.5.25 PARI

The PARI is a part of the broadcast identity, which uniquely identifies an IPBS/IPBL. This
PARI is automatically assigned to each IPBS/IPBL in the system. But if more than one Ascom
IP-DECT system operates within the same coverage area, the systems need to have a
unique system identity in the PARI assigned in order to differentiate the systems.
To see the occupied system IDs of other Ascom IP-DECT systems within the coverage area,
perform an RFP scan, see
1 Select DECT > PARI.
NOTE: To access the PARI tab, the PARI function has to be enabled, see
Enable PARI Function
15 February 2012 / Ver. H
8.5.23 Enter IP Address to the PARI Master and the
on page 99.
on page 94.
on page 68.
8.1.5 Configure the NTP Settings
8.3.1 Configure IP Settings
8.21.10 RFP Scan
on page 94.
8.22 Reset
Forward Alarms and Events
8.1.4 Configure Automatic Firmware
on page 68.
on page 81.
on page 137.
TD 92579EN
on page 138.
on page 70.
8.5.15
99
