Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
8.3.2

Routing

View the IP routing by Select IP > Routing.
8.4

LDAP

The Lightweight Directory Access Protocol (LDAP) protocol is required for systems in which
the server and a replicating client access a joint user database. All IPBSs/IPBLs in the system
have access to the database, one of the IPBSs/IPBLs can be configured to be the LDAP
server.
The joint user database contains information about the users registered in the system. It
also contains the system configuration, that is the configurations made under the DECT
menu.
This section describes how to do the following configurations and settings.

• Configure LDAP Server

• Check LDAP Server Status

• Configure LDAP Replicator
• Check LDAP Replicator Status
8.4.1 Configure LDAP Server
The IP-DECT system needs an LDAP server in some configurations. If the VoIP gateway is
set up as an LDAP server, the Master should be set up as an LDAP replicator, see
Configure LDAP Replicator
Setup the IPBS/IPBL as an LDAP server
Note: The selected user name and password must be the same in both the Master and the
Standby Master. If a Multi Master system is used, the Masters must also have the same
user name and password.
1 Select LDAP > Server.
2 Add a user, for example ldap-user, in the User text field.
3 Enter a password in the Password text field.
4 Select the Write Access check box.
5 Click "OK".
8.4.2 Check LDAP Server Status
Select LDAP > Server Status
The following information is displayed:
• connections - Total number of active connections to the LDAP server
15 February 2012 / Ver. H
on page 83.
TD 92579EN
8.4.3
82
