Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
Code
Severity
Remote
Source
Description

8.21.5 Performance

It is possible to check different performance parameters. For a description of the
parameters, see the table below.
Figure 32.
Parameter
CPU
CPU-R
MEM
Concurrent calls
Temperature (only for IPBL)
Voltage (only for IPBL)
Current (only for IPBL)
1 Select Diagnostics > Performance
2 Select the checkbox(es) for the desired performance statistics.
3 Click "OK".
4 One window shows statistics for the last 24 hours. The maximum possible value is
displayed in the top-left corner. Click the left or right arrow buttons to see different
time frames.

8.21.6 Config Show

Under Diagnostics > Config Show, the configuration is displayed as a text output.
15 February 2012 / Ver. H
A unique number that identifies the alarm. Click the
code to get more detailed information about the
alarm. For a list of possible codes and their
descriptions, see 10.2 Fault Code Descriptions
page 142.
It has three possible states:
• Critical - Immediate action is
required. It is displayed, for
example, if a managed object goes
out of service.
• Major - Urgent action is required. It
is displayed, for example, if the
capability of the managed object is
severely degraded.
• Indeterminate - Level of severity
cannot be determined
The IP Address of the object that reported the alarm.
Click the IP address to access the object.
The software module that reported the alarm.
Together with the code it uniquely identifies an
alarm.
A textual description of the alarm.
Description
Shows CPU utilization
Shows utilization of CPU resources allocated by
different tasks
Shows memory utilization
Shows the number of ongoing calls
Shows the temperature of the cabinet
Shows the power supply voltage level
Shows the power supply current consumption
TD 92579EN
on
136
