Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)

8.21.7 Ping

The ping function is used to determine the response time from the IPBS/IPBL to a certain IP
address. It can be used to analyse the connection between the IP-DECT system
components.
1 Select Diagnostics > Ping.
2 Enter an IP address in the IP Address text field.
3 Press "Enter" on the keyboard.

8.21.8 Traceroute

The traceroute function displays how packets travel from the IPBS/IPBL to a certain IP
address. The result is an ordered list of IP addresses with the measured round trip time.
1 Select Diagnostics > Traceroute.
2 Enter an IP address in the IP Address text field.
3 Press "Enter" on the keyboard.

8.21.9 Environment

This section only applies to the IPBL.
The environment tab gives information power supply and consumption. It also display
temperature and fan status.
1 Select Diagnostics > Environment.
2 The following information is available in the Power section:
• Power supply - AC or DC power port.
• Voltage - input voltage.
• Current consumption - total consumption for the IPBL an the connected RFPs.
– Max 4,0 A when supplied with AC power port
– Max 5,2 A when supplied with DC power port
Figure 33.
3 The following information is available in the Environment section:
• Temperature - °C
• Fan status - OK, not OK

8.21.10 RFP Scan

This section only applies to the IPBS.
To scan for occupied system IDs of other IP-DECT systems within the coverage area,
perform an RFP scan following the steps below.
Note: Executing an RFP scan will terminate all calls on the IPBS.
1 Select Diagostics > RFP Scan
2 Click "Start Scanning"

8.21.11 Service Report

To download a service report do the following:
1 Select Diagnostics > Service Report.
2 Click "download".
15 February 2012 / Ver. H
TD 92579EN
137
