Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
6 Click "Move".
Existing RFPI on the new Radio is replaced by the broken Radio's RFPI. The new
Radio's RFPI is now released and can be reused. All other RFPIs in use are not
affected. The broken Radio will be deleted from the Static Registrations section.

8.10.2 RFPs

This section only applies to the IPBL.
Information about the DECT devices connected to the IPBL. For explanation on the
information, see the table below.
1 Select Device Overview > RFPs.
2 Click the applicable port to open the RFP details pop-up window.
Figure 25. å
Figure 26.
Port
Status
Description
RFPI
SW Version
Hardware
Boot
Connected Time
Cable Delay
Tx Error
Rx Error
3 The following actions are available:
• Click "OK" to save your settings and close the pop-up window.
• Click "Cancel" to close the pop-up window.
• Click "Refresh" to update the information.
• Click "Reset" to reset the RFP.

8.10.3 Sync Ring

This section only applies to the IPBL.
A wire map of the synchronization ring is available in the GUI. The identities (IPBL-xx-xx-xx)
of the IPBLs and the position in the ring is displayed. If the ring is broken it is possible to
locate where. Click the IP address to access another IPBL.
1 Select DECT Sync > Sync Ring.

8.10.4 Sync Ports

This section only applies to the IPBL.
Displays the current status of the synchronization ports.
1 Select DECT Sync > Sync Ports.
Status
15 February 2012 / Ver. H
The port used in the IPBL.
Current status of the IPBS connected to the IPBL.
A short description to help identify the IPBS.
Identity number.
The current software version.
The hardware version.
RFP boot version.
The elapsed time since the RFP connected to the IPBL.
The delay caused by the cable.
The number of transmitting errors.
The number of receiving errors.
The current status of the port.
TD 92579EN
109
