Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
• Gatekeeper ID
3 Click "OK".

8.13.2 Interfaces

Select Gateway > Interfaces.
This page shows the gateway's interfaces organized into columns. The individual columns
are explained in the table below.
Column
Interface
CGPN In,
CDPN In,
CGPN Out,
CDPN Out
State
Alias
Registration
TEST Interface
Normally there is one non-configurable, internal TEST interface called TEST, usable only as
the destination for a call. If a call is received on this interface, the on hold music stored in
the non-volatile memory is played. Incoming calls must be in G.729A or G.723 format;
other formats are not supported. Suffix dialling digits are ignored.

8.13.3 SIP Interfaces

1 Select Gateway > SIP.
2 Click on one of the SIP interfaces (SIP1 - SIP4) under the Interface heading. A new
window opens.
15 February 2012 / Ver. H
The Gatekeeper Identifier.
This is used with VOIP interfaces (GWn) configured as
"Gatekeeper/Registrar" as Gatekeeper Identifier
(H.323) or Registrar Name (SIP), see
Interfaces
If multiple gatekeepers are installed in a network this
can be used to find the right gatekeeper using
Gatekeeper Discovery.
If a PBX is enabled on the same system a different
Gatekeeper Identifier must be used for Gateway and
PBX.
Values Description
The descriptive name of the interface. Click this name to open a
page, on which all settings can be configured. For more
information, see
CGPN In, CDPN In, CGPN Out and CDPN Out mappings.
Click the "+" sign next to the interface name to bring up
mapping details. For more information see
CDPN) Mappings
The current state of the interface at protocol level. Possible
states are: Up, Down.
The H.323 call name and the E.164 call number.
If a terminal has successfully registered with an SIP or TEST
interface, then this is indicated in this column through
specification of the IP address <Name of the interface:Call
number:IP address>.
on page 119.
on page 115.
TEST Interface
on page 118.
TD 92579EN
8.13.4 Gatekeeper
Call Number (CGPN/
115
