Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
5 Select the Enable Pari function check box.
If SIP protocol is used, continue with step 5 to 10 below:
6 Enter the IP address to the SIP proxy (registrar) in the Proxy text field.
7 Enter the IP address to the alternative SIP proxy (registrar) in the Alt. Proxy text field.
8 Select the Enbloc Dialing check box.
9 Select the Allow DTMF through RTP check box.
10 Select the Register with number check box.
11 To update the Web GUI, press CTRL+F5 on the keyboard or close the Web GUI and
start it again in order to make the new menu to appear.
12 If H.323 protocol is used: Enter the address to the gatekeeper in the Gatekeeper IP
Address text field.
13 Reset in order to make the changes take effect, see
8.15.5 Configuration After Updating the Firmware From Software Version 3.x.x to
Later
Master/Standby Master Configuration
When upgrading from version 3.x.x to later the MWI will automatically be set to Off. If the
MWI was enabled prior to the upgrade: Select DECT > Suppl. Serv. and select an MWI
mode in the MWI Mode drop-down list.
When upgrading a system from software version 3.x.x to later, existing system
administration accounts remain configured locally in the IPBS(s)/IPBL(s). However, it is
recommended that the system administration accounts are configured centrally instead by
moving them to the Kerberos server. To have the system administration accounts
configured locally is a potential security risk. For information on how to configure
Kerberos, see
on page 61.
Kerberos
To move the system administration accounts to the Kerberos server, do as follows:
Step 1: For each IPBS/IPBL where system administration accounts have been configured
locally, do as follows:
1 Select General > Admin.
2 Go to the Additional Administrator and Auditor Accounts section.
3 Write down each accounts configuration data such as the user name, password
(when known) and role.
Step 2: On the Kerberos server, do as follows:
1 Select General > Kerberos Server.
2 Go to the Users section and enter the configuration data for each account that was
written down in step 1 above.
3 Click "OK".
Step 3: For each IPBS/IPBL where system administration accounts have been configured
locally, do as follows to delete the local system administration accounts:
15 February 2012 / Ver. H
8.1.3 Centralized Management of Administrator/Auditor Accounts Using
TD 92579EN
8.22 Reset.
129
