Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
2.3

IPBL

The following versions of the IPBL are available:
• IPBL IP-DECT Gateway VAC/VDC (for 110/230 VAC or 48 VDC)
• IPBL IP-DECT Gateway VDC (for 48 VDC)
2.3.1

Overview

lan
1
1 2 3
Figure 4. Overview of the IPBL
Pos. Name
1 Reset
2 Status LED
3 Lan
4 Synchronization
5 Reference
6 Base station 01-16
2.3.2

Power Supply

The power supply are located at the rear of the IPBL. The IPBL can be powered using the
following alternatives:
• 110/230 VAC (only IPBL IP-DECT Gateway VAC/VDC)
• 48 VDC
Note: For more information, see
Software
The software in the IPBL can be updated by downloading new software without
disconnecting the equipment. The new software is stored in flash memory. See
Update on page 130 for information.
15 February 2012 / Ver. H
synchronization reference
2 ring in ring out in out
4 5
Function
Resets the IPBL, see
page 138 for more information.
Indicates the status on the IPBL.
10BASE-T/100BASE-T Ethernet interface.
LAN1 port must be used in the IP-DECT system (LAN2 port
is for administration only).
Sync ring in and sync ring out interfaces.
Reference sync in and reference sync out interfaces.
ISDN U
6.3 Power the IPBL
base station 01 02 03 04 05 06
09 10 11 12 13 14
6
8.23 Reset Using the Reset Button
DECT base station interfaces.
PN
on page 40.
TD 92579EN
07 08
15 16
