Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
• Identity Header
when Sending
INVITE
• Reliability of
Provisional
Responses
Internal Registration
• Protocol
4 Click "OK".
Call Number (CGPN/CDPN) Mappings
For every interface, it is possible to store mappings for CGPN In, CDPN In, CGPN Out and
CDPN Out (explained in the table below), enabling call numbers and call number formats
to be adjusted for incoming and outgoing calls.
Call Number Mappings Table
Map name
CGPN In
CDPN In
CGPN Out
CDPN Out
1 Select Gateway > SIP.
2 For the interface that you want to set up call number modifications on, click the
"+" sign next to the interface name. A new window opens and call number
mapping can be made for the interface.
3 Select one of the following mapping lines.
Field name
• CGPN in
15 February 2012 / Ver. H
Interoperability option for outgoing calls. This controls
the way CGPN is transmitted to the SIP provider.
Possible values are:
- CGPN is user part of URI - The Identity header
contains an URI with the calling party number as user
part (left from @).
- Fixed AOR - The Identity header contains the fixed
registration URI (AOR). The actual calling party number
and name will be transmitted inside the P-Preferred-
Identity header (RFC 3325).
This controls the way the option tag "100 rel" is
offered.
Possible values are:
- Supported - The tag is an optional extension.
- Required - The tag is a mandatory extension.
- Disabled - The tag is not offered.
Select "None" in the drop-down list, which is the
default value.
Description
Calling Party Number In
Called Party Number In
Calling Party Number Out
Called Party Number Out
Description
if you want to edit the calling number of incoming calls.
Digits used for the headmatch on the received number. In
addition to the normal dialling digits (0..9,*,#) the
following characters have special meaning:
R If 'R' is used as first digit of the number only numbers
with 'presentation restricted' match. In this case the
'presentation restricted' property is cleared if 'R' is not
used on 'Number Out'.
? Can be used at any place inside the number and means
that any received digit matches.
Used to
edit the calling number of incoming calls
edit the called number of incoming calls
edit the calling number of outgoing calls
edit the called number of outgoing calls
