Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
10 Click "Upload".
Note: If the CSR file generated in step 5 is deleted before receiving the reply from the CA
(in step 8) it will not be possible to upload the signed certificate file in step 10. The system
will automatically delete the CSR file when step 10 has completed.

8.1.11 License

Select Configuration > General > License.
Licenses are used to activate additional functions in the IP-DECT system. Which functions
that are activated are depending on type of license.
Do as follows:
1 In the License Key field: Enter a license number.
2 Click "OK".
8.2

LAN

This section describes how to do the following configurations and settings.

• Set DHCP mode

• Set IP static address
• Set dynamic IP address
• Set link type
• Configure VLAN
• View LAN statistics
• Deactivate LAN port (only for IPBL)
Note: The IPBL has two LAN ports. LAN1 port must be used in the IP-DECT system (LAN2
port is for administration only).
8.2.1 Set DHCP Mode
The IPBS/IPBL can have different DHCP modes, see the table below.
Figure 20.
Disabled
Client
Automatic
Change DCHP mode following the steps below.
1 On the IPBS: Select LAN > DHCP.
On the IPBL: Select LAN1 > DHCP.
2 Select DCHP mode in the Mode drop-down list.
3 Click "OK".
15 February 2012 / Ver. H
Used if the IPBS/IPBL should have a static IP address.
The IPBS/IPBL acts as a DHCP Client, if there is a DHCP server in
the network it will be assigned an IP address
In automatic DHCP mode the IPBS/IPBL will act as a DHCP
client on power up.
If the IPBS/IPBL is restarted by shortly pressing the reset button
it will get the IP address 192.168.0.1 and the netmask
255.255.255.0 for the LAN1 port.
