Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
2 Select the Encryption check box.
NOTES:
3 Click "OK".
8.7.2

Device Management

If a specific Device Manager (for example IMS3) is to be used in the IP-DECT system, enter
the IP address to the Device Manager following the steps below. To set the Master to
search for an existing Device Manager on the network, go to
page 104.
1 Select UNITE > Device Management.
NOTE: To access the Device Management tab, the Master mode has to be activated,
see 8.5.13 Select Mode
2 Enter the address to the Device Manager in the Unite IP Address text field.
The IP address for the Device Manager that the Master is currently connected to is
shown under Active Settings.
3 Click "OK".
8.7.3

Service Discovery

If no Device Manager (for example IMS3) has been selected to be used in the IP-DECT
system, see
search for an existing Device Manager on the network. To set the Master to search in a
specific domain on the network or to stop the search, follow the steps below.
1 Select UNITE > Service Discovery.
NOTE: To access the Service Discovery tab, the Master mode has to be activated, see
8.5.13 Select Mode
2 Do one of the following:
• To stop the Master to search for a Device Manager, select the Disable check box.
• To set the Master to search for a Device Manager in a specific domain on the
network, enter the domain id in the Domain ID text field. The domain id must be
the same as the one entered in the Device Manager.
3 Click "OK".
8.7.4

Send Status Log

It is possible to send alarm and event reports to the Unite system. For example directly to
the ESS fault handler or to the UNA (Unite Node Assistant) which in turn forwards the
alarm event according to distribution lists.
1 Select UNITE > Status Log.
2 Enter the address to the server where the Status Log should be sent in the Unite IP
Address text field.
3 Enter the Resource Identity/Service in the Unite Resource Identity text field. If this
field is left empty then the default will be UNA (Unite Node Assistant).
15 February 2012 / Ver. H
a) When selecting or clearing the Encryption check box, it may take
up to a couple of minutes until the IMS3/Unite CM is fully
operational..
b) The IMS3/Unite CM support for encryption is depending on the
IMS3/Unite CM software version.
on page 94.
8.7.2 Device Management
on page 94.
8.7.3 Service Discovery
on page 104, then the Master will automatically
TD 92579EN
on
104
