Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
TFTP mode
Error
Fatal error
Deployment:
Good sync
Deployment:
Bad sync
Deployment:
No sync
2.2.2

IPBS2 with External Antennas

This section contains the differences between the IPBS2 with internal antenna and the
IPBS2 with external antennas. For all other information see
Antenna on page 6.
Figure 3. IPBS2 with MCX connectors for external antennas.
Contents of the Box
The box in which the IPBS2 is packed contains:
• An IPBS2 with external antennas.
15 February 2012 / Ver. H
Solid yellow.
100 ms red, 100 ms off.
Solid red.
2000 ms blue, 400 ms yellow.
400 ms blue, 600 ms off, 400 ms blue,
600 ms off, 400 ms yellow.
2000 ms red, 400 ms yellow.
Back view while lying down
MCX connectors
TD 92579EN
TFTP mode.
No Ethernet connection.
Fatal hardware error.
The IPBS2 is in deployment
mode and has good air sync
coverage.
The IPBS2 is in deployment
mode and does not have
adequate air sync coverage.
The IPBS2 is in deployment
mode and has no air sync
coverage.
2.2.1 IPBS2 with Internal
