Software Upgrade; Before Upgrading; Upgrading Sequence - ASCOM IPBS Installation And Operation Manual

Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
3 Click "Save" in the dialogue window and browse to the place where the
configuration should be saved.
4 Click "Save".

8.15 Software Upgrade

Note: In software version 5.0.x:
The RFP version information is not displayed in the IPBS2 GUI. RFP software is more
integrated now and this information becomes obsolete. In IPBS1 the RFP software has a
separate flash memory, but this is not the case for IPBS2. On the IPBS1 the RFP version is
still displayed.

8.15.1 Before Upgrading

1 For safety, take a backup of the configuration parameters for the Master and
Standby Master.
2 Make a note of the Master and Standby Master IP address.
On the device configured as Master, continue with step 3 to 6 below.
3 When upgrading from software version 2.x.x to later: Select DECT > SMS and make
a note of the IMS3 IP address.
4 When upgrading from software version 2.x.x to later: Select DECT > Master and
make a note of the SIP proxy (registrar) IP address, found in the Gatekeeper IP
Address text field.
5 When upgrading from software version 2.x.x to later: Select DECT > Master and
make a note of the alternative SIP proxy (registrar) IP address, found in the Alt.
Gatekeeper IP Address text field.

8.15.2 Upgrading Sequence

The best order is to start with the firmware and boot file upgrade of the Standby Master,
then the Master, then all Radios, then do the configuration changes. This way the Radios
will not be able to connect to the Master or Standby Master with incompatible firmware.
The upgrading sequence is as follows:
1 Upgrade firmware and boot file of Standby Master, see
2 Upgrade firmware and boot file of Master, see
3 Upgrade firmware and boot file of Radios, see
4 When upgrading from software version 2.x.x to later: Update configuration of
Radios, see
Version 2.x.x to
5 When upgrading from software version 2.x.x to later: Update configuration of
Master, see
Version 2.x.x to
6 When upgrading from software version 2.x.x to later: Update configuration of
Standby Master, see
Software Version 2.x.x to
7 When upgrading from software version 3.x.x to later: Update configuration of
Master and Standby Master, see
From Software Version 3.x.x to
15 February 2012 / Ver. H
8.15.4 Configuration After Updating the Firmware From Software
Later.
8.15.4 Configuration After Updating the Firmware From Software
Later.
8.15.4 Configuration After Updating the Firmware From
Later.
8.15.5 Configuration After Updating the Firmware
Later.
TD 92579EN
8.15.3 IPBS/IPBL
8.15.3 IPBS/IPBL Upgrade.
8.15.3 IPBS/IPBL Upgrade.
Upgrade.
127
