Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
4
If "Client" or "Automatic" is set, reset to make the changes take effect. See
Reset
8.2.2
Set a Static IP Address
It is necessary for the Master and the Standby Master to have static IP addresses. The
Radios can have dynamic IP addresses retrieved from the network DHCP server.
Ask the network administrator to reserve an IP address for the Master and Standby Master.
1
On the IPBS: Select LAN > DHCP.
On the IPBL: Select LAN1 > DHCP.
2
Select "Disabled" in the Mode drop-down list.
3
Click "OK".
4
Do NOT reset the device yet. Set a static IP address first.
1
On the IPBS: Select LAN > IP.
On the IPBL: Select LAN1 > IP.
2
Enter "IP Address", "Network Mask", "Default Gateway" and "DNS Server"
addresses provided by the network administrator in the text fields.
You can also enter an alternative DNS Server in the Alt. DNS Server text field and
select the Check ARP check box to detect and prevent ARP poisoning attacks.
3
Click "OK".
4
Reset in order to make the changes take effect, see
5
Start the web-based configuration, using the static IP address.
8.2.3
Dynamic IP address via DHCP
The Radios can have dynamic IP address allocation if the network has an DHCP server.
1
On the IPBS: Select LAN > DHCP.
On the IPBL: Select LAN1 > DHCP.
2
Select "Client" in the Mode drop-down list.
3
Click "OK".
4
Reset in order to make the changes take effect, see
Note: If the DHCP lease time is shorter than the time-to-live of the name/IP address
association in the Windows Internet Name Service (WINS) server, it may cause a mismatch,
and a wrong device may be reached if its WINS name is used.
8.2.4
Link
1
On the IPBS: Select LAN > Link.
On the IPBL: Select LAN1 > Link.
The link setting should be set to "auto" under all normal circumstances.
8.2.5
Configure VLAN
Identity and priority settings for VLAN are done in the "LAN > VLAN" sub menu.
Note: It is necessary to have a VLAN with the same ID as configured in the IPBS/IPBL,
otherwise it will not be possible to access the IPBS/IPBL.
15 February 2012 / Ver. H
on page 138.
TD 92579EN
8.22 Reset
on page 138.
8.22 Reset
on page 138.
8.22
80
