Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
Interfaces sif:cgpn:cgnm -
Protocols
Coders
Numbers
Uptime
State

8.14 Backup

The IPBS/IPBL configuration can be downloaded and saved on a disc or a server. This is
useful when identical configuration should be applied to several IPBSs/IPBLs, for example
when configuring the Radios in a system. For information on how to load a saved
configuration on the IPBS/IPBL, see
1 Select Backup > Config.
2 Click "download".
Click "download with standard password" to save the configuration with the
default system password.
15 February 2012 / Ver. H
>dif:cdpn:cdnm/ ccn
AProtocol/BProtocol
ACoders/BCoders
Coder,ms (round, jitter)
Caller->Called
d:h:m:s
8.18 Update
Sif: Interface for incoming call.
Cgpn: calling number, before
routing.
Cgnm: calling name before routing.
Dif: Interface for the outgoing call.
Cdpn: called number after routing.
Cdnm: called name after routing.
ccn: Name of the call counter used
for this route (call counter name).
The protocol used on the calling and
the called side.
Encoder used from A to>B or B to>
Coder: voice compression used.
ms: packeting used.
round: Transmission duration in ms.
jitter: Variance of transmission delay
in ms.
Caller The number of the caller as
transmitted to the call destination.
Called The number dialled.
The uptime of the call in days, hours,
minutes and seconds.
Dialling Dialling is in progress.
Alerting The dialled distant terminal is being
called.
Connected The call is connected.
Clearing The call has been terminated by one
of the two parties.
on page 130.
TD 92579EN
126
