Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
If multiple RFPs are selected for update, they will be updated one at a time If /sequence
command is used.
Example Update RFP Firmware
This example shows an "update file" for the IPBL.
mod cmd UP1 check ser 20070316-1
mod cmd RFP_UPDATE0 firmware http://172.20.8.125/ascom/rfp/
Worf123.S2
mod cmd RFP_UPDATE0 select 0xffff
mod cmd RFP_UPDATE0 start /idle
Example IPBS1/IPBS2/IPBL Boot and Firmware Update
This example shows an "update file" for the IPBS1/IPBS2 and IPBL.
mod cmd UP0 prot http://172.20.8.128/ascom/firmware/ ireset
5.0.0
mod cmd UP0 boot http://172.20.8.128/ascom/boot/ ireset 5.0.0
A.1.7 Configuration File Backup
To make a backup of the configuration file, use the following command:
mod cmd UP0 scfg <url> [<final-command> <save-serial> [ /force
<hours>]]
The scfg command uploads the current configuration file to the specified <url>.
Example
mod cmd UP0 scfg http://192.168.0.10/configs/saved/#h#b5.txt no-
op WEEKLY /force 168
The command above saves the device configuration file once a week with a backlog of 5
weeks.
To load a configuration file on the IP-DECT device use the following command:
mod cmd UP0 cfg <url> <final-command> <serial>
The command loads the configuration file, and all commands in it are executed.
15 February 2012 / Ver. H
TD 92579EN
152
