Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
3 If you have selected the "Standby" mode: Enter the primary Mobility Master IP
address in its text field.
4 Write a login name in the Name text field.
5 Enter a password in the Password text field.
6 Click "OK".

8.5.19 Connect Mobilty Master to other Mobility Master(s)

1 Select DECT > Mobilty Master.
2 Write a name in the Name text field.
3 Enter a password in the Password text field.
4 Enter the address to the other Mobility Master in the IP Address text field.
5 Enter the address to the Standby Mobility Master for the other Mobility Master in
the Alt. IP Address text field.
6 Click "OK".
7 Repeat the above steps to connect to additional Mobility Masters.

8.5.20 Disconnect Mobilty Master from other Mobility Master(s)

1 Select DECT > Mobilty Master.
2 Delete the name in the Name text field.
3 Delete the password in the Password text field.
4 Delete the address to the other Mobility Master in the IP Address text field.
5 Delete the address to the Standby Mobility Master for the other Mobility Master in
the Alt. IP Address text field.
6 Click "OK".
7 Repeat the above steps to disconnect from additional Mobility Masters.
Note: When disconnecting from other Mobility Master(s) the password field might have to
be reentered.

8.5.21 Connect Master to a Mobility Master

In a system with several Masters, all Masters must be connected to the Mobility Master.
1 Select DECT > Master.
2 Enter the name for the Mobility Master in the Name text field.
3 Enter the password for the Mobility Master in the Password text field.
4 Enter the address to the Mobility Master in the IP Address text field.
5 Enter the address to the Standby Mobility Master in the Alt. IP Address text field.
6 Click "OK".
7 Reset in order to make the changes take effect, see

8.5.22 Enable the Radio

If the IPBS/IPBL not shall be used as a radio, for example only be used as a PARI Master, it
can be disabled by marking the Disable checkbox.
15 February 2012 / Ver. H
TD 92579EN
8.22 Reset on page 138.
98
