Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
8.9.5

Export the Users to a csv file

The Users can be exported to a csv file, for example for editing or backup reasons.
1
Click "Export".
2
Click "Save" in the dialog window that appears.
3
Enter a name of the file and select in which folder the file should be saved.
4
Click "Save".
Note: For safety reasons, the Auth. Code and Password will not be included in the csv file.
8.9.6

Show Anonymous

The IPEI / IPDI number is displayed on anonymous registered handsets.
1
Select "Users".
2
Select "Anonymous".

8.10 Device Overview

8.10.1 Radios

Information about the devices in the IP-DECT system.
1
Select Device Overview > Radios.
Figure 23.
Name
RFPI
15 February 2012 / Ver. H
The unique identification name. The name syntax
is ipbs-xx-xx-xx (or ipbl-xx-xx-xx), where xx-xx-xx
should be replaced with the last 6 hexadecimal
digits of the MAC address.
Radio Fixed Part Identity.
TD 92579EN
107
