Figure 10. Minimum distances between a cable duct and the mounting bracket
5.2.5
Connect External Antennas (only IPBS2 and DB1)
1
Position the included antenna bracket above the mounting bracket with a
minimum distance of 74 mm (250 mm maximum) and mark the two holes for the
antenna bracket, see
When using wall plugs: Drill the two holes using a ∅ 6 mm drill and insert the
2
included wall plugs.
Position the antenna bracket to the wall and fasten it with the two included ∅ 3.5
3
mm screws.
4
Mount the two included coaxial cables on the antenna bracket
31 (2). Fasten the coaxial cables with the lock nuts which are found on the coaxial
cable antenna connectors.
5
Mount the antennas on the antenna connectors (2).
15 February 2012 / Ver. H
Figure 8.
57 mm
75 mm
15 mm thick cable ducts
figure 11
on page 31 (1).
65 mm
TOP
125 mm
70 mm
figure 11
TD 92579EN
on page
30
