Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
2 For the interface, that you want to add a CGPN map, click the "->" sign under the
CGPN map heading.
A new window opens.
Figure 31. Number In – Number Out
3 Under "Number in" define the number type and –prefix that you wish to have
replaced. The number type is denoted using the abbreviation from the Call Number
Formats Table (see
4 Define the substitution under "Number out".
5 Click "OK".
Note: All call numbers in IP-DECT are always processed in "unknown" format. That is why
the result of a number replacement for incoming calls, always is of the type "unknown"
and the call number type of outgoing calls to be replaced is likewise always "unknown".
Accordingly, you cannot specify a number type for replacements of incoming numbers in
the "Number out" field and for replacements of outgoing numbers in the "Number in"
field.

8.13.6 Show Active Calls

Select Gateway > Calls.
On this page you can see the currently active calls on all configured gateway interfaces.
Calls from the IP-DECT Master does not normally display here.
The individual columns are explained in the table below.
Column
15 February 2012 / Ver. H
Figure 29.
Call Number Formats Table
Format Values
on page 119).
Description
TD 92579EN
