Installation and Operation Manual
IP-DECT Base Station & IP-DECT Gateway (software version 5.0.x)
IP Address
Sync
Region
Device Name
LDAP
Version
Connected Time
Figure 24.
Add Radios
In the Uninitalized Registrations section, uninitialized Radios not registered to a PARI
Master are shown.
1 Select Device Overview > Radios
2 Click "Add" to add the Radio to the Master.
3 In the Add Radio window enter a name for the device. You can also add a Standby
Master IP Address and a Sync Region.
4 Click "OK".
5 The Radio restarts and it establishes a connection to the PARI Master only.
Delete Radios
In the Static Registrations section, initialized Radios no longer registered to the PARI
Master are shown.
1 Select Device Overview > Radios
2 In the Static Registrations section, click "Delete" to delete the Radio.
The Radio's RFPI is now released and can be reused. All other RFPIs in use are not
affected.
Move RFPIs
In the Static Registrations section, initialized Radios no longer registered to the PARI
Master are shown. If it is vital that the new device keeps the RFPI for the broken device
e.g. alarm localization purposes, move the RFPI for the broken device to the new device
registered to the PARI Master.
1 Connect the replacing device.
2 Add the Radio to the PARI Master, see
3 Select Device Overview > Radios
4 In the Static Registrations section, click "Move" for the Radio that is broken.
5 In the Move RFPI window, select in the Destination section the new Radio that you
want to move the broken Radio's RFPI to.
15 February 2012 / Ver. H
The IP address, click on the IP address to access
the configuration GUI of that IPBS/IPBL.
The current synchronization status.
Should be "Master OK", "Slave OK" or "Standby
OK" if synchronized. "Standby" is a Radio
configured as a Sync Master but it is active.
The sync region which the Radio belongs to.
The name entered in the general menu.
The LDAP status, can be "" (blank), "-", "up",
"server" or "down".
Should be "-", "up" or "server".
The current software version.
The elapsed time since connected to the Master.
on page 108.
Add Radios
TD 92579EN
108
