Using the Web Management Interface (WMI)

The Web Management Interface (WMI) is a "graphical" version of the Command Line
Interface, comprised of HTML files. The HTML files are embedded in the Access Gateway
and are dynamically linked to the system's functional command sets. You can access the WMI
from any Web browser.
Your browser preferences or Internet options should be set to compare loaded
pages with cached pages.
To connect to the Web Management Interface, do the following:
1. Establish a connection to the Internet.
Open your Web browser.
2.
3. Enter the network interface IP address of the Access Gateway (set up during the
installation process).
Log in as usual (supplying your user name and password).
4.
To access any menu item from the WMI, click on the item you want. The corresponding work
screen then appears in the right side frame. From here you can control the features and settings
related to your selection. Although the appearance is very different from the Command Line
Interface, the information displayed to you is basically the same. The only difference between
the two interfaces is in the method used for making selections and applying your changes
(selections are checkable boxes, and applying your changes is achieved by pressing the
button). Pressing the
changes without applying them).
Selecting the language of the Web Management Interface
You can click on Language Selection to change the language of the Web Management Interface
text. Currently English (U.S.) and Chinese (simplified) are provided.
80
button resets the screen to its previous state (clearing all your
Reset
A G
CCESS ATEWAY
Submit
System Administration
