AG 2300, AG 3100, AG 5600 and Metro Bundle Quick Start
This quick start document provides instructions and reference material for getting started with the
Nomadix Access Gateway products, specifically the AG 2300, AG 3100, AG 5600 and AG 5600
Metro Bundle. If you have any problems, please contact our technical support team at
+1.818.575.2590, or email: support@nomadix.com.
Accessory Box Contents
AG 2300, AG 3100
1 – NSE Accessory CD
1 – U.S. (NEMA 5-15p) Power Cord
1 – EU (Schuko CEE7/7) Power Cord
1 - 6' Serial Null Modem Cable
2 - Rack Mount Brackets
1 – Bumper and Screw Kit
Start Here
1. Unpack the Nomadix Access Gateway and place the product on a flat and stable work
surface.
2. Register the gateway for support services by completing and returning the Nomadix
Gateway Registration Form - hardcopy enclosed or obtain the form online at
http://www.nomadix.com/registration.
3. Connect the power cord.
4. There are two ways to connect to the Access Gateway:
a. Serial Connection:
i. For AG 5600 and Metro, connect the RJ45 console cable (6ft. length) to
the product's console port and the DB9 female to the computer. For AG
2300 and AG 3100, connect the DB9 female-to-female (NULL) serial
cable (6ft. length) between the product's serial interface and your
computer.
ii. Start a HyperTerminal session to communicate with the AG via the
product's serial interface. Use the following configuration settings for
your session:
Bits per Second
P/N 200-1021-001-M
Copyright © 2011 Nomadix, Inc.
AG 5600, AG 5600 Metro Bundle
1 - NSE Accessory CD
1 – U.S. (NEMA 5-15p) Power Cord
1 - EU (Schuko CEE7/7) Power Cord
1 - 6' RJ45 – DB9 Console Cable
2 - Rack Mount Brackets
1 – Bumper and Screw Kit
Data Bits
9600
8
Parity
Stop Bits
Flow Control
None
1
None
| 1 |

Advertisement

loading
Need help?

Need help?

Do you have a question about the AG 2300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Nomadix AG 2300

  • Page 1 This quick start document provides instructions and reference material for getting started with the Nomadix Access Gateway products, specifically the AG 2300, AG 3100, AG 5600 and AG 5600 Metro Bundle. If you have any problems, please contact our technical support team at +1.818.575.2590, or email: support@nomadix.com.
  • Page 2 Access Gateway Quick Start (cont’d) b. Subscriber-side Ethernet Connection: i. Connect a cross-over Ethernet cable between the product’s “subscriber port” and your computer’s Ethernet port. ii. Setup a SSH client to establish a SSH session to communicate with the NSE gateway via the administrative IP address after the Access Gateway finishes powering up.
  • Page 3 Access Gateway Quick Start (cont’d) Configuration Note: The network side of the AG must be connected to a live network that can access the Internet, or you will not be able to receive the License Key from our server (Step 3). Step 1: Configuring IP and DNS information Static IP Configuration For an AG with a Static IP address, enter IP address and DNS information as shown in...
  • Page 4 Access Gateway Quick Start (cont’d) Domain Name nomadix.com Host Name (no spaces) Primary DNS Server (mandatory) 198.6.1.1 Secondary DNS Server (optional) 198.6.1.2 Tertiary DNS Server (optional) 198.6.1.4 You will be asked to reboot after you enter the DNS information. Please enter (y)es when prompted to reboot.
  • Page 5: Pppoe Client Configuration

    Access Gateway Quick Start (cont’d) Sample Screen Responses IP and DNS Parameters PPPoE Client Configuration For an AG with network configuration set to PPPoE client, enter DNS information as shown in step 1c and PPPoE client configuration information as shown in step 1d. Please note that in case of PPPoE client, only the tertiary DNS server is configurable.
  • Page 6 Access Gateway Quick Start (cont’d) Step 1c: Entering your DNS Information DNS Parameter Your Settings Examples Domain Name nomadix.com Host Name (no spaces) Primary DNS Server (not configurable) Secondary DNS Server (not configurable) Tertiary DNS Server (optional) 198.6.1.2 Step 1d: Entering your PPPoE Information...
  • Page 7 Access Gateway Quick Start (cont’d) Sample Screen Responses DNS Parameters and PPPoE Configuration You will be asked to reboot after you enter this information. Please enter (y)es when prompted to reboot. | 7 |...
  • Page 8 EULA before the AG can retrieve its License Key. To retrieve the License Key, enter [es] at the prompt. The AG retrieves the License Key from the Nomadix License Key Server, then reboots the gateway receives a valid license from our server for NOTE: The date and time...
  • Page 9: Step 5: Configuring The System

    Access Gateway Quick Start (cont’d) another DHCP pool. The total lease pool size recommendation is 50% more than the number of licensed subscribers. DHCP Parameter Your Settings Examples DHCP Services (Disable) DHCP Relay (Yes / No) If No, skip to DHCP Server DHCP Relay Server IP Address blank DHCP Relay Agent IP Address...
