Displaying the Port-Location Mappings {List}

You can display a listing of all port-locations assigned to this system.
To view the listing of port-location assignments, go to the Web Management Interface, click on
, then click on
Port-Location

Subscriber Intra-Port Communication

If enabled, subscribers on a same port location (for example, a conference room) can
communicate with each other without NSE intervention.
Subscribers can communicate with each other when on the same VLAN and the same IP
subnet. The NSE will not respond to any ARP requests from the subscriber for other
subscribers (or hosts) that are on the same port-location subnet.
Subscriber Side
Subscribers in same port/location
To enable intra-port communication
Click
1. Port-Location
Assignment screen appears.
System Administration
The List Port-Location Assignments screen appears:
List.
NSE
-> . Click on the
List
Network Side
number. The Process Port-Location
Port
215
