This manual provides information for planning, installing, programming, and testing this security
system. When necessary, this manual refers you to other documentation included with compati-
ble peripherals.
Planning sheets are included for you to record hardware layout and software programming set-
tings.
About the User's Guide
The User's Guide (466-1513-01) contains user worksheets that should be filled out during the
installation and programming of the system. With two partition systems, a User's Manual for
each partition is suggested.
Special Installation Requirements
This security system can be used as a fire warning system, an intrusion alarm system, an emer-
gency notification system, or any combination of the three.
Some installations may require configurations dictated by city/state codes, insurance, or Under-
writer's Laboratories (UL). This section describes the various component and configuration list-
ings.
UL Listed Installations
This section describes the requirements for UL Listed installations.
Basic System
•
Control Panel (60-734-01 Hybrid or 60-792-01-95R Integrated)
•
Backup Battery 12V 4 AH (60-681) or 12V 7 AH (60-680)
®
•
SuperBus
2000 Fixed Display Touchpad (60-820), 2x16 LCD Touchpad (60-746-01), 2x20
LCD Touchpad (60-803), or 2x20 VFD Touchpad (60-804)
•
Standard Class II 24 VAC, 30 VA Power Transformer (60-761), Class II 24 VAC, 30 VA
Line Carrier Power Transformer (60-762), or Standard Class II 24 VAC, 50 VA Power
Transformer (60-778), Class II 24 VAC, 50 VA Line Carrier Power Transformer (60-779)
•
Interior Speaker Siren (60-528), Exterior Speaker Siren (13-060), Slim Line Hardwire Inte-
rior Siren (60-483-01) or Hardwire Exterior Siren (13-046) per partition
Basic system may also include a SuperBus 2000 RF Receiver (60-764-01-95R-16Z) or
(60-764-01-95R-32Z) or (60-764-01-95R-MAX).
Household Burglary Alarm System Unit (UL 1023)
Basic system, plus:
•
Hardwire Magnetic Contact (13-068 or 13-071) or Wireless Learn Mode Door/Window Sen-
sor (60-362)
•
Immediate Beeps set to on
•
UL 98 Options set to on
•
Receiver Failure set to on (if wireless devices are used)
•
Siren Verify set to on
•
Exit Delay set to 60 seconds
•
Quick Exit set to off
•
Siren Timeout set to 4 minutes or more
•
Entry Delay set to 45 seconds or less
•
RF TX Timeout set to 24 hours (if system includes a built in or SuperBus 2000 RF Receiver
and wireless smoke sensors)
•
Extended Delay set to off
•
Sleep Time set to off
•
Two Trip Error set to off
•
Alarm Verify set to off
•
Disable Trouble Beeps set to off
Household Fire Warning System (UL 985)
Basic system, plus:
