Touchpad Brightness (042)
This setting lets the user lighten or darken the background on
touchpad displays. Each touchpad can be set to compensate for
lighting conditions in the touchpad location.
Volume (043)
This setting determines the volume level of status
sounds from speakers connected to the Phone Interface/
Voice Module.
Note
This menu appears only if a Phone Interface/Voice Module
is connected to the panel.
Voice Chime (044)
This setting determines whether speakers connected to
the Phone Interface/Voice Module announce perimeter
sensor/zone numbers that are tripped when the Chime
feature is on. For example, "Sensor one open."
Note
This menu appears only if a Phone Interface/Voice Module
is connected to the panel.
Chime On Close (045)
When this setting is on, the panel sounds a single chime
when a perimeter door or window is closed.
Concord

Set Up Schedules Menu

The menu lets you set up time frames for light control and exception opening/
SET UP SCHEDULES
.
closing reports The system (all partitions) allows you to set up to 16 schedules (00–15).
Setting up schedules consists of setting a start and stop time for each schedule, then selecting
which days of the week the schedule will be active. You can also set up a rollover schedule,
which starts on one day and ends on another day. This saves programming time and leaves more
schedules available (in case they are needed later).
Rollover Schedule Example: To set up a schedule to rollover from Tuesday evening to Wednes-
day morning, set a schedule start time for 2200 (10:00
Set the schedule to turn on Tuesday. Because the stop time is set for morning, the system auto-
matically carries the schedule over to the next day.
If you use the same start and stop times described above and set the schedule to turn on Monday
through Friday, then one schedule will cover the entire week.
¾
To adjust Touchpad Brightness:
1. Press A or B until the display shows
2. Press #, then A or B until the display shows
BRIGHTNESS n
3. Enter a setting from 0 (darkest background) to 3 (brightest
background). The display flashes the entered selection.
# and the display shows the new setting.
Press
¾
To adjust status sound Volume:
1. Press A or B until the display shows
2. Next, press A or B until the display shows
setting).
3. Enter a setting from 0 (off) to 7 (loudest). The display flashes the
entered selection. Press
¾
To turn Voice Chime off or on:
1. Press A or B until the display shows
2. Press # then A or B until the display shows
(current setting).
ON
3. 1 (off) or 2 (on). The display flashes the entered selection.
Press
Press # and the display shows the new setting.
¾
To turn Chime On Close off or on:
1. Press A or B until the display shows
2. Press # then A or B until the display shows
(current setting).
OFF/ON
3. Press 1 (off) or 2 (on). The display flashes the entered selection.
Press # and the display shows the new setting.
Options (Default = 2)
OPTIONS
(current setting).
Options (Default = 4)
, then press #.
OPTIONS
VOLUME n
# and the display shows the new setting.
Options (Default = on)
.
OPTIONS
VOICE CHIME OFF/
Options (Default = off)
.
OPTIONS
CHIME ON CLOSE
. .) and a stop time for 0500 (5:00
P M
.
TOUCHPAD
(current
. .).
A M
