Onboard Options Menu - GE Interlogix Concord Security System Installation Instructions Manual

Output Programming (output 1: 101001,
output 2: 101011, output 3: 101021,
output 4: 101031)
This setting lets you assign a partition and a 5-digit
configuration number for each SnapCard relay out-
put. This number determines both which system event
activates the output and the duration or time the out-
put is activated.
1. Partition: the system partition (1 or 2).
2. Configuration number: The combination of a
trigger and a response.
Trigger: the event that activates the output point.
Trigger events can be partition alarms, trouble
conditions, open sensors, etc. (see Appendix B:
Reference Tables).
Response: how the output responds when trigger
event occurs (see Appendix B: Reference
Tables).
Output Text (output 1: 10110, output 2: 10111,
output 3: 10112, output 4: 10113)
Entering text for an output allows the user to control it directly
or by schedule. Use the following guidelines to "name" Snap-
Card outputs:
• Use the item numbers that appear in "Appendix B, Table
B2" for characters and words listed there.
Note
If you desire an output for User Output Control you must use the
Output Text feature to name the output. If no Output Text is pro-
grammed, the user will not have access to the output.
• If a desired word does not appear in Table B2, create it
using the characters (custom text).
• When using words from Table B2, spaces between them
appear automatically. When using characters from Table B2
to create words, you must reserve an item number for a
'space' after the word.
• Each character or word uses up one item number. For exam-
ple, a word from the list counts as one item number. A cre-
ated word (such as BOY'S) counts as six item numbers—4
letters, 1 apostrophe, and 1 space.
• Only 16 item numbers are allowed for each output name, so
plan ahead before programming output text. You may need
to abbreviate words to avoid running out of item numbers.
Concord
¾
1.
2.
3.
4.
5.
6.
7.

Onboard Options Menu

The menu lets you set up the following built-in options:
ONBOARD OPTIONS
• INPUTS —This menu lets you turn the Smoke Verification and the Two Wire Smoke features
off or on.
• OUTPUT PROGRAMMING
panel outputs and assign the outputs to partitions.
• —This menu lets you assign text to the output allowing the output to be con-
OUTPUT TEXT
trolled by the user.
The following sections describe the settings that appear under
Acc. Modules-SnapCards-Output Programming
(Defaults: Partition Assign=all, Configuration Output 1= 01400,
Output 2 = 00410, Output 3 = 00903, Output 4 = 01003)
To assign configuration numbers to SnapCard Relay outputs
(where tttrr is the point configuration number, ttt is the trigger
number and rr is the response number):
With the display showing
until the display shows
Press # again and the display shows
Press A or B to select the desired output (1–4), then press #.
With the display showing
select the desired partition. Press # to confirm the partition.
Press A or B until the display shows
setting).
Enter the desired 5-digit configuration number for this relay. Press
# to confirm the setting.
Press # and repeat steps 3 through 6 until all outputs are pro-
grammed.
Acc. Modules-SnapCards-Output Text (Default = none)
¾
To program Output Text:
1. With the display showing
or B until the display shows
2. Press # and the display shows
3. Press A or B until the desired output number is dis-
played.
4. Press # and the display shows:
.Where
ITEM 0
is the character/word number.
5. Enter the number of the desired character or word, or scroll
through the numbers by pressing
ward). If you make a mistake, simply enter the correct
number or continue scrolling through choices.
# to accept the displayed choice and the display
6. Press
shows:
OUTPUT N ITEM 1 0 -
7. Repeat steps 4 and 5 as needed to complete the output
name.
* after entering the last character or word number.
8. Press
The display shows the complete text name. For example:
OUTPUT 1 GARAGE DOOR
—This menu lets you set configuration numbers for the two built-in
, press #. Then press A or B
SNAPCARDS
.
OUTPUT PROGRAMMING
.
OUTPUT 1
, press 1 or 2 to
PARTITION ASSIGN 1
CONFIGURATION tttrr
, press #, then A
SNAPCARDS
OUTPUT TEXT
.
OUTPUT 1
OUTPUT N ITEM 0 0 -
is the first character/word location and
B (forward) or A (back-
.
.
ONBOARD OPTIONS—INPUTS
