Concord
Part No.
Hardwire Sensors/Detectors
13-068 Magnetic Contact 3/8" press fit
13-070 Magnetic Contact – surface mount
System Sensor models 2100D, 2100TD, 2100S,
N/A 2100TS, 2400, or 2400TH or ESL series 429AT,
521B or 521BXT
13-082 PIR Motion Detector
Sirens
60-736* Supervised Wireless Siren
60-483-01 Slim Line Hardwire Interior Siren
13-046 Hardwire Exterior Siren
SuperBus 2000/Miscellaneous Components
60-746-01 2x16 LCD Alphanumeric Touchpad
60-820 Fixed Display LCD Touchpad
60-803 2x20 LCD Alphanumeric Touchpad
60-804 2x20 VFD Alphanumeric Touchpad
60-777-01 Phone Interface/Voice Module
60-764-01-95R RF Receiver
60-755 Power Line Carrier Card
60-756 4 Input/2 Output SnapCard
60-757 8Z Hardwire Zone Expander SnapCard
60-758 4 Output SnapCard
60-774 Hardwire Input Module
60-770 Hardwire Output Module
60-620-01 Energy Saver Module
60-677* Interrogator 200 Audio Verification Module
60-850*
Standard
Cellular Backup Module
60-850-01*
High Power
60-783-02* Automation Module
Total power consumption:
Total power consumption using 30 VA transformer and 4.0 AH backup battery not to
exceed:
Total power consumption using 50 VA transformer and 7.0 AH backup battery not to
exceed:
*
These devices not listed, investigated, or verified by UL.
Listed, but not tested for compatibility by UL.
†
Table A2: Hardwire Devices
Description
mA
Qty. Sub Total
(Max.)
N/A
N/A
10 mA
10 mA
N/A
120 mA
145 mA
90 mA
30 mA
120 mA
120 mA
600 mA
30 mA
110 mA
185 mA
230 mA
130 mA
18 mA
91 mA
20 mA
10 mA
1600 mA
1900 mA
35 mA
mA
1,000 mA
2,000 mA
