Specifications

99
Power Requirements: .....Class II, 24 VAC, 30 or 50 VA, 60 Hz
Rechargeable Batteries: ..12 VDC, 4Ah Lead-Acid (part no. 60-681) OR 12 VDC, 7Ah (part no. 60-680).
The battery will last 24 hours with no AC and specified standby load
Radio Frequency: ............319.5 MHz
Nominal Range: ...............1000 feet (305 meters) typical open air
Storage Temperature Range:- 30° to 140° F (-34° to 60° C)
Operating Temperature Range: 32° to 120 ° F (0° to 49° C)
Maximum Humidity: ......90% Relative Humidity (non-condensing)
Auxiliary Power Output: 12 V @ 1.0 A (30 VA Transformer) OR 2.0 A (50 VA Transformer)
Dimensions: .....................12 in. (30.5 cm) x 12 in. (30.5 cm) x 3.0 in. (7.6 cm) (H x W x D)
