Note
In UL Listed installations, the
Phone Interface/Voice Mod-
ule is for supplementary use
only.
Note
For RJ-31X connections,
see "Installing an RJ-31X
Phone Jack (13-081).
19

SuperBus 2000 Phone Interface/Voice Module (60-777-01)

The Phone Interface/Voice Module includes two backplates for mounting the module inside the
control panel cabinet. The module can also be mounted outside of the control panel using an
optional plastic housing (part no. 60-800). Refer to the SuperBus 2000 Phone Interface/Voice
Module Installation Instructions included with each module, for complete mounting instructions.
The module requires panel power and bus connections, phone line connection through panel ter-
minals and DB-8 cord (from an RJ-31X jack), and speaker connection through panel terminals.
Wiring—Power
Connect the module to the panel power and bus terminals as shown in Figure 19.
Wiring—Phone Line
For partition 1, connect the phone line to the module through the panel terminals and DB-8 cord
(from an RJ-31X jack) as shown in Figure 20. For partition 2 phone connection, see the Super-
Bus 2000 Phone Interface/Voice Module Installation Instructions.
G N D + 1 2 V A
Panel
3 4 5
Terminals
Receiver Module
Terminal Strip
+ 1 2 V A B G N D
Figure 18. Wiring the SuperBus 2000 RF Receiver
Phone Interface/Voice Phone Interface/Voice
Module Terminal Strip 1 Module Terminal Strip 2
4 5 6 7
2 8
3
1
A B
+12V
+12V
GND A B
6
3 4 5
Panel Terminals
Figure 19. Wiring the Phone Interface/Voice Module
Phone Interface/Voice Phone Interface/Voice
Module Terminal Strip 2
Module Terminal Strip 1
1 2 3 4 5 6 7
+ 1 2 V A B G N D G N D S P K 1 S P K 2 A U D 1
Grn Brn
Panel Terminals 2 4 2 5
6 0 7 3 4 1 0 9 d . d s f
Figure 20. Connecting a Phone Line to the Module
B U S B
6
9 10 11 12 13
14
8 9 1 0 1 1 1 2 1 3 1 4
A U D 2 G N D T I P 1 T I P 2 R I N G R I N G
2 1
Red
Gry
2 6 2 7
DB-8 Cord
Plug
Brn Gry
Grn
Red
RJ-31X Jack
Concord
