Exception Reports (Opening:
062nn, Closing: 063nn, where
nn=Schedule number [0 to 15])
This setting lets you attach the Exception
Opening report feature and the Exception
Closing report feature to time schedules.
Lights (064xnn where nn=Sched-
ule number [0 to 15] and x=light
number [1 to 9] minus 1)
This setting lets you attach light controls to a
time schedule.
Outputs (065xnn where nn=Sched-
ule number [0 to 15] and x=output
number [1 to 6] minus 1)
This setting lets you attach outputs to a time
schedule. Onboard outputs are 1–2, Snap-
Card outputs are 3–6.
Note
Outputs can only be scheduled if text has been
entered in installer programming. Only onboard
and SnapCard outputs can be scheduled.
Arming (0660nn where nn=Sched-
ule number [0 to 15])
This setting lets you arm according to a time
schedule.
Note
This setting will allow you to arm to AWAY only.
There is no disarm schedule.
Concord
¾
To Attach a Schedule to Exception Opening or Exception Closing:
1. Press A or B until the display shows
2. Press # then A or B until the display shows
.
TION CLOSING
3. Press # and the display shows
want a different schedule, press A or B until the desired schedule appears.
4. Press 1 (off) or 2 (on). The display flashes the entered selection. Press # and the
display shows the new setting for the selected schedule.
¾
To Attach Schedules to Lights:
1. Press A or B until the display shows
2. Press # then A or B until the display shows
menu.
LIGHTS
3. Press A or B until the desired light appears.
4. Press # and the display shows
want a different schedule, press A or B until the desired schedule appears.
5. Press 1 (off) or 2 (on). The display flashes the entered selection. Press # and
the display shows the new setting for the selected schedule.
6. Repeat steps 3, 4, and 5 until all desired lights are attached to schedules.
¾
To Attach Schedules to Outputs:
1. Press A or B until the display shows
2. Press # then A or B until the display shows
menu.
OUTPUTS
3. Press A or B until the desired output appears.
4. Press # and the display shows
want a different schedule, press A or B until the desired schedule appears.
5. Press 1 (off) or 2 (on). The display flashes the entered selection. Press # and
the display shows the new setting for the selected schedule.
6. Repeat steps 3, 4, and 5 until all desired outputs are attached to schedules.
¾
To Attach Schedules to Arming:
1. Press A or B until the display shows
2. Press # then A or B until the display shows
3. To select arm to AWAY press #.
4. Press # and the display shows
want a different schedule, press A or B until the desired schedule appears.
5. Press 1 (off) or 2 (on). The display flashes the entered selection. Press # and
the display shows the new setting for the selected schedule.
6. Repeat steps 4 and 5 until all desired schedules are attached.
Attach Schedules to Events (Default = off)
ATTACH SCHEDULES TO EVENTS
EXCEPTION OPENING OR EXCEP-
(current setting). If you
SCHEDULE 00 OFF/ON
Attach Schedules to Events (Default = off)
ATTACH SCHEDULES TO EVENTS
. Press # to enter the
LIGHTS
(current setting). If you
SCHEDULE 00 OFF/ON
Attach Schedules to Events (Default = off)
ATTACH SCHEDULES TO EVENTS
. Press É to enter the
OUTPUTS
(current setting). If you
SCHEDULE 00 OFF/ON
Attach Schedules to Events (Default = off)
ATTACH SCHEDULES TO EVENTS
.
ARMING
(current setting). If you
SCHEDULE 00 OFF/ON
.
.
.
.
