About This Manual

This manual provides information for planning, installing,
programming, and testing this security system. When nec-
essary, this manual refers you to other documentation
included with compatible devices.
Planning sheets are included for you to record hardware
layout and software programming settings.

Special Installation Requirements

This security system can be used as a fire warning system,
an intrusion alarm system, an emergency notification sys-
tem, or any combination of the three.
Some installations may require configurations dictated by
city or state codes, insurance, or Underwriter's Laborato-
ries (UL). This section describes the various component
and configuration listings.
UL Listed Systems
This section describes the requirements for UL Listed sys-
tems.
Basic System
‰ Control Panel (60-806-95R)
‰ Backup Battery, 12 VDC, 4 AH (60-681)
‰ SuperBus 2000 2x16 LCD Touchpad (60-746-01),
SuperBus 2000 Fixed Display Touchpad (60-820),
SuperBus 2000 2x20 LCD Touchpads (60-803, 60-
809), or SuperBus 2000 2x20 VFD Touchpads (60-
804, 60-810)
‰ Standard Class II 16.5 VAC, 25 VA Power Trans-
former; manufacturer—Tech Electro Ind, Inc. Part
No. 48A0164 (60-822)
‰ 15-Watt, Dual Tone Siren (13-469) or Hardwire Siren
(13-046)
Household Burglary Alarm System Unit (UL 1023 )
Basic system, plus:
‰ Hardwire Magnetic Contact (13-068 or 13-071) or
Wireless Learn Mode Door/Window Sensor (60-362),
Wireless Learn Mode PIR Motion Sensor (60-703-95,
60-511, or 60-639)
‰ IMMEDIATE TROUBLE BEEPS set to on
‰ UL 98 OPTIONS set to on (see page page 28)
‰ RECEIVER FAILURE set to on
‰ AC FAILURE set to on
‰ EXIT DELAY set to 60 seconds or less
‰ QUICK EXIT set to off
‰ EXIT EXTENSION set to off
‰ SIREN TIMEOUT set to 4 minutes or more
‰ SIREN VERIFY set to on
‰ ENTRY DELAY set to 45 seconds or less
Household Fire Warning System (UL 985)
Basic system plus:
‰ Hardwire Smoke Detector:
System Sensor models 2100D, 2100TD, 2100S,
2100TS, 2400, or 2400TH learned into Sensor Group
26
Sentrol (ESL) models 429AT, 521B, or 521BXT
learned into sensor group 26
‰ Wireless Smoke Sensor 60-506-319.5 learned into
sensor group 26
‰ IMMEDIATE TROUBLE BEEPS set to on
‰ UL 98 OPTIONS set to on (see page page 28)
‰ RECEIVER FAILURE set to on
‰ AC FAILURE set to on
‰ SIREN VERIFY set to on
UL 1023 & 985 24-Hour Backup
‰ For 24-hour backup, the total current draw for all con-
nected devices is limited to 90 mA continuous using a
4.0 AH battery.
Central Station Reporting
The panel has been tested with the following central sta-
tion receivers using SIA and Contact ID reporting formats:
‰ CS-5000 Central Station Receiver
‰ Sur-Gard Central Station Receiver with models SG-
DRL2A and SG-CPM2
UL-Canada Listed Systems
This section describes the requirements for ULC (UL Can-
ada) Listed systems.
‰ CSA Certified Accessories
The UL-Canada Basic System is nearly the same as
the "UL Basic System" described previously, the only
difference being that you must use the 60-679-CN
Class II transformer (Basler part number BE 116250-
AAA) to power the panel.
‰ Residential Burglary Alarm System Unit
(CAN/ULC-S309)
Same as "UL Basic System and Household Burglary
Alarm System Unit (UL 1023)" described previously.
Residential Fire Warning System Control Unit
(CAN/ULC-S545-M89)
Same as "UL Basic System and Household Fire Warning
System (UL 985)" described previously.
œÌi
For 24-hour backup, external power drain is limited
to 90 mA continuous using a 4.0AH battery.
California State Fire Marshall Listed Systems
Same as Household Fire Warning System (UL 985),
plus:
‰ SMOKE VERIFY must be set to off
