SWS Supv Code (0703)
This setting determines the system house code number used for supervising wireless
sirens.
Note
To supervise wireless sirens, Concord hardwire panels must include a SuperBus 2000 RF
Receiver. For all Concord panels, the siren must be learned into sensor group 33 for the sys-
tem to process radio signals from wireless sirens.
Supervised Wireless Sirens receive signals from the panel through the existing electri-
cal wiring. If sirens fail to receive or process these signals, the siren transmits a wire-
less signal to the panel/ receiver.
Note
You must set both the SWS Supv Code and the partition House Code (see the
menu) before plugging in Supervised Wireless Sirens.
TROL
Global Fire (0704)
This setting determines whether or not sirens in both partitions sound
(on) if either partition activates a fire alarm.
Siren Verify (0710)
This setting determines whether or not the panel supervises the panel
speaker terminals (7–8). When this feature is on, the panel will indicate a
trouble condition if no speaker is connected to panel speaker terminals.
Note
For UL Listed installations, Siren Verify must be set to on.
49
The following sections describe the settings that appear under

Sensors Menu

The menu gives you access to the following settings:
SENSORS
• LEARN SENSORS lets you add (learn) hardwire zones, wireless sensors, and wireless touch-
pads into panel memory.
• lets you "name" the sensors and zones you have added to the system.
SENSOR TEXT
• lets you delete zones and sensors from panel memory.
DELETE SENSORS
• lets you view and, if desired, change a sensor group or partition assignment.
EDIT SENSORS
You can also identify whether a zone is wireless or hardwire, whether it is configured as
Normally Closed (N/C) or Normally Open (N/O), or if the zone is a touchpad.
Sensor
Hardwire Zones
Wireless Sensors
Wireless Door/Window Sensors
with External Contacts
Self Actuated Bell
-
LIGHT CON
Siren Options-Global (Default = off)
¾
To turn Global Fire off or on:
1. With the display showing
(current setting), press 1 (off) or 2 (on). The dis-
play flashes the entered setting.
2. Press # and the display shows the new setting.
Siren Options-Partition 1 (Default = off)
¾
To turn Siren Verify off or on:
1. With the display showing
(current setting), press 1 (off) or 2 (on).
ON
The display flashes the entered setting.
2. Press # and the display shows the new setting.
Table 7: How to Trip Sensors
Steps to Trip Sensor
Start with the zone in its "normal" state, then trip the zone into
its alarm state. A normally closed door, for example, should be
closed when you begin the Learn Sensors process. To trip the
zone, open the door.
Follow the instructions included with each sensor.
Place the external contact in the alarm condition, then activate
the sensor tamper switch.
Activate the tamper switch.
Siren Options-Global (Default = 3)
¾
To set the SWS Supv Code:
1. With the display showing
(current code),
SUPV CODE nnn
enter the desired code (1–255).
The display flashes the entered
code.
2. Press # and the display shows the
new code.
GLOBAL FIRE OFF/ON
SIREN OPTIONS—PARTITION 1
SIREN VERIFY OFF/
SWS
.
Concord
