Enabling the Tangential Emulation

Tangential emulation control can be individually enabled or disabled by pen condition.
Press the MENU key to select MENU mode.
Press the NEXT key.
Press the NEXT key again.
Press the F4 key to select FUNCTION 2 .
Press the F4 key to select TANGENT EMULATION .
Press the F4 key to toggle between
ENABLE/DISABLE.
Press the [F1] key to [F4] key as required to
enable/disable the tangential emulation mode per
each condition of numbers.
Press the ENTER key to register your settings.
Press the MENU key to cancel MENU mode.
In READY status, the message TANGENTIAL appears along
with the condition menu when the condition on which the enabled
tangential emulation is selected .
Advanced Functions and Settings ♦ C4 - 31
INTERFACE>
AREA PARAMETERS>
FUNCTION 1>
FUNCTION 2>
DATA SORTING>
AXIS ALIGNMENT>
AUTO PRE FEED>
TANGENT EMULATION>
TANGENTIAL
EMULATION
MODE>
ENABLE/DISABLE>
TANGENTIAL OFF-1
EMULATION OFF-2
OFF-3
OFF-4
CONDITION 2 14
30
READY TANGENTIAL
