GRAPHTEC FC4100 series User Manual page 119

Troubleshooting – Plotter does not Operate Properly
Problem
As soon as the data
is sent to plotter, pen
carriage or media
moves then stops.
Display shows
WORKING.
Processing Indicator
LED lights.
As soon as the data
is sent to plotter, pen
carriage or media do
not move at all.
Display shows
WORKING.
Processing Indicator
LED lights.
Origin point seems to
be shifted to center,
although origin button
is not pressed.
As soon as the data
is sent to the plotter,
the media comes off,
then MEDIA END
message appears.
COMMAND ERROR
message appears.
INSTRUCTION NOT
RECOGNIZED
message appears.
Plotter does not cut
beyond certain
length.
Too much pen
up/down action is
performed.
Plotter cuts on foot
print of grit rollers.
Test Modes and Troubleshooting ♦ C6 - 9
Cause
Position of the plot
data is located
beyond the effective
cutting area.
Origin point might be
set at lower left
although the plot data
is created based on
center origin.
Origin point might be
set at center although
the plot data is
created based on
lower left origin.
ROLL-1 or ROLL-2 is
selected for sheet
media and the origin
is set as center.
Data from PC is not
received correctly.
Data from PC is not
received correctly.
PAGE LENGTH is
not set correctly.
TANGENTIAL
EMULATION is
enabled.
EXPAND setting.
Solution
Adjust the position of
the data on
application software.
Check the origin
setting.
Check the origin
setting.
Select SHEET for
sheet media.
Check the cut area by
pressing the ENTER
key.
Set PAGE LENGTH
correctly.
Normal.
If TANGENTIAL is
displayed on the
READY menu,
change the condition
number on which the
TANGENTIAL
EMULATION is not
enabled or disable
the EMULATION.
Set EXPAND zero if
necessary.
See section
Origin
Origin
Loading Media
Page Length
Tangential Emulation
Expand
