3. Then lower the pinch rollers (raise the lever) and pull
the vinyl out from the alignment bar.
4. Re-adjust the position of the roll as necessary to remove slack between the roll and pinch
rollers.
The length of the media at the front of the plotter should be sufficient to completely
NOTE:
cover the paper sensor. If the front edge extends too far when you have pulled the
media taut, wind the media back onto the roll.
To view video to loading media.
NOTE:
For PC:
Open the Manual CD.
Double click on the Load.avi file to start viewing the video or run Media Player, then
open Load.avi file.
For Macintosh:
Open the Manual CD.
Double click on the Load.mov file to start viewing the video.
Preparing to Cut ♦ C3 - 16
