Axis Alignment Adjustment

When the light pointer is selected and the AXIS ALIGNMENT key is pressed, the pen carriage
and media move into position so that the light pointer is in the same position as the cutter/pen in
READY mode. In this case, the position of the light pointer represents the position of the
cutter/pen in READY mode.
If the loupe or bombsight has been selected, neither the pen carriage nor the media will move
evenly, even though the AXIS ALIGNMENT key has been pressed because the loupe is already in
the same position as the cutter/pen in READY mode. The light pointer does not light. If you are
pointing to a registration mark colored with an illegible color such as red, use the loupe.
Press the ALIGNMENT key to select the Axis
Alignment mode.
Then the Axis Alignment menu appears.
Press the POSITION key to move the light
pointer or the loupe to the Axis Point 1.
Press the ENTER key to store the setting.
The following menu appears.
Press the POSITION key to move the light
pointer or the loupe to the Axis Point 2.
Press the ENTER key to store the setting.
If select the two point method, the Axis Origin
Point menu appears. If you select the three
point method, the Axis Point 3 menu appears.
Press the POSITION key to move the light
pointer or the loupe to the Axis Point 3.
Press the ENTER key to store the setting.
The following menu appears.
If the distance between point 1 and point 2 is
unknown press ENTER key to skip to the next
step.
If the distance between point 1 and point 2 is
known value, use the POSITION key to change
the distance value to that of the printed image
the distance between point 1 and point 2. The
measured distance shown on the 3
the actual distance on the 4
Press the RIGHT or LEFT ARROW key to
move the cursor.
Press the UP or DOWN key to increase or
decrease the number of distance value.
Advanced Functions and Settings ♦ C4 - 26
rd
row. Set
th
row.
AXIS POINT
1
X=
0 mm
Y=
0 mm
AXIS POINT
1
X=+
10 mm
Y=+
8 mm
AXIS POINT
2
X=+
410 mm
Y=+
9 mm
AXIS POINT
3
X=+
9 mm
Y=+
408 mm
DISTANCE
POINT 1-2
00399.6 mm
OK?
00400.0 mm
