GRAPHTEC FC4100 series User Manual page 114

Press the F4 key to select DATA DUMP.
The following message appears.
Confirm pen is mounted on the carriage.
Press the F3 key to select DONE and start plotting.
Press the F4 key to select CANCEL CONDITIONS.
You have to turn off the plotter to cancel DUMP, if the plotter is in DUMP mode.
The following prompt message appears.
Transmit the data from the computer. As the data is received, the character data is printed as
ASCII codes and the non-character (control) data is plotted as two-digit hexadecimal values (e.g.,
Line Feed = 0A, Carriage Return = 0D, ETX = 03).
When all of the data has been printed, turn off the plotter to cancel DUMP mode.
Test Modes and Troubleshooting ♦ C6 - 4
CONDITION LIST>
SELF TEST>
DATA DUMP>
MOUNT THE PEN!
DONE>
CANCEL CONDITIONS>
PRINT DATA DUMP
