Specifications

Table B-1 provides the DS Series Door Station Specifications.
Item
Door Station
Speaker
Microphone
Door Latch Relay
Wiring Requirements
DSC3 Color Camera Specifications
Imager
Auto Iris
Lux
Resolution
Horiz. Viewing Angle
Vert. Viewing Angle
Swivel
Video Output
Video Output Impedance
Power Requirements (Min.)
DSC3 and DSF3 Faceplate Dimensions
DSS3 Specifications
DSS3 Dimensions
© ELAN Home Systems 2009 • All rights reserved.
Table B-1 Specifications
Description
8 ohm, sealed back polyester cone
Hi-gain omni-directional condenser
12VDC coil, 2A contact rating
Cat-5, 1000ft max
1/3 in. CCD
1/50-1/100,000 sec.
.05 min.
480 TV Lines
120°
100°
+15°/-15° left to right
1V peak-to-peak
75 Ohms
12VDC @ 130 mA
5 1/2 W X 3 8/10 H (in)
138 W X 97 H (mm)
5 1/2 W X 3 8/10 H (in) X 9/10 D (in)
138 W X 97 H (mm) X 23 D (mm)
C2
INSTALLATION MANUAL
Page 59
